The Fortinet NSE7_LED-7.0 exam consists of 60 multiple-choice questions that are to be completed within 120 minutes. The questions are designed to test the candidate’s knowledge of the Fortinet Security Fabric and their ability to apply it to secure LAN Edge networks. A minimum score of 50% is required to pass the exam and obtain the NSE 7 certification.

Fortinet NSE7 certification is an advanced-level certification that demonstrates an individual’s expertise in implementing and managing Fortinet’s cybersecurity solutions. The NSE7 certification has several specializations, including NSE7_FWF-6.2 (Fortinet NSE 7 – FortiWiFi 6.2), NSE7_SAC-6.2 (Fortinet NSE 7 – Secure Access 6.2), and NSE7_EFW-6.2 (Fortinet NSE 7 – Enterprise Firewall 6.2). One of the latest specializations is the Fortinet NSE7_LED-7.0 (Fortinet NSE 7 – LAN Edge 7.0).

NEW QUESTION 10
Refer to the exhibit

Examine the FortiGate RSSO configuration shown in the exhibit
FortiGate is configured to receive RADIUS accounting messages on port3 to authenticate RSSO users The users are located behind port3 and the internet link is connected to port1 FortiGate is processing incoming RADIUS accounting messages successfully and RSSO users are getting associated with the RSSO Group user group However all the users are able to access the internet, and the administrator wants to restrict internet access to RSSO users only Which configuration change should the administrator make to fix the problem?

Enable Security Fabric Connection on port3

Create a second firewall policy from port3 lo port1 and select the target destination subnets

Add RSSO Group to the firewall policy

Change the RADIUS Attribute Value selling to match the name of the RADIUS attribute containing the group membership information of the RSSO users

NEW QUESTION 11
Which CLI command should an administrator use to view the certificate verification process in real time?

diagnose debug application foauthd -1

diagnose debug application radiusd -1

diagnose debug application authd -1

diagnose debug application fnbamd -1

NEW QUESTION 12
Which CLI command should an administrator use to view the certificate verification process in real time?

diagnose debug application authd -1

diagnose debug application foauthd -1

diagnose debug application radiusd -1

diagnose debug application fnbamd -1

NEW QUESTION 13
Refer to the exhibit

A device connected to port2 on FortiSwitch cannot access the network The port is assigned a security policy to enforce 802 1X authentication While troubleshooting the issue, the administrator obtains the debug output shown in the exhibit Which two scenarios are likely to cause this issue? (Choose two.)

The device is not configured for 802 IX authentication.

The device has been quarantined for 3600 seconds.

The device has been assigned the guest VLAN

The device does not support 802 1X authentication

NEW QUESTION 14
Refer to the exhibit.

Examine the FortiGate user group configuration and the Windows AD LDAP group membership information shown in the exhibit FortiGate is configured to authenticate SSL VPN users against Windows AD using LDAP The administrator configured the SSL VPN user group for SSL VPN users However the administrator noticed that both the student and j smith users can connect to SSL VPN Which change can the administrator make on FortiGate to restrict the SSL VPN service to the student user only?

In the SSL VPN user group configuration set Group Nam to CN-SSLVPN, CN=”users, DC-trainingAD, DC-training, DC-lab

In the SSL VPN user group configuration, change Name to cn=sslvpn, CN=users, DC=trainingAD, Detraining, DC-lab.

In the SSL VPN user group configuration set Group Name to ::;=Domain users.CN-Users/DC=trainingAD, DC-training, DC=lab.

In the SSL VPN user group configuration change Type to Fortinet Single Sign-On (FSSO)

NEW QUESTION 15
Exhibit.

Exhibit.

Refer to the exhibits
In the wireless configuration shown in the exhibits, an AP is deployed in a remote site and has a wireless network (VAP) called Corporate deployed to it The network is a tunneled network however clients connecting to a wireless network require access to a local printer Clients are trying to print to a printer on the remote site but are unable to do so Which configuration change is required to allow clients connected to the Corporate SSID to print locally?

Configure split-tunneling in the vap configuration

Configure split-tunneling in the wtp-profile configuration

Disable the Block Intra-SSID Traffic (intra-vap-privacy) setting on the SSID (VAP) profile

Configure the printer as a wireless client on the Corporate wireless network

NEW QUESTION 16
Refer to the exhibit.

Examine the FortiGate configuration FortiAnalyzer logs and FortiGate widget shown in the exhibit An administrator is testing the Security Fabric quarantine automation The administrator added FortiAnalyzer to the Security Fabric and configured an automation stitch to automatically quarantine compromised devices The test device (::.:.:.!) s connected to a managed Fort Switch dev :e After trying to access a malicious website from the test device, the administrator verifies that FortiAnalyzer has a log (or the test connection However the device is not getting quarantined by FortiGate as shown in the quarantine widget Which two scenarios are likely to cause this issue? (Choose two)

The web filtering rating service is not working

FortiAnalyzer does not have a valid threat detection services license

The device does not have FortiClient installed

FortiAnalyzer does not consider the malicious website an indicator of compromise (IOC)

NEW QUESTION 17
Refer to the exhibit.

Examine the network diagram and packet capture shown in the exhibit
The packet capture was taken between FortiGate and FortiAuthenticator and shows a RADIUS Access-Request packet sent by FortiSwitch to FortiAuthenticator through FortiGate Why does the User-Name attribute in the RADIUS Access-Request packet contain the client MAC address?

The client is performing AD machine authentication

FortiSwitch is authenticating the client using MAC authentication bypass

The client is performing user authentication

FortiSwitch is sending a RADIUS accounting message to FortiAuthenticator

NEW QUESTION 18
Refer to the exhibits

The exhibits show the wireless network (VAP) SSID profiles defined on FortiManager and an AP profile assigned to a group of APs that are supported by FortiGate None of the APs are broadcasting the SSlDs defined by the AP profile Which changes do you need to make to enable the SSIDs to broadcast?

In the SSIDs section enable Tunnel

Enable one channel in the Channels section

Enable multiple channels in the Channels section and enable Radio Resource Provision

In the SSIDs section enable Manual and assign the networks manually

NEW QUESTION 19
An administrator is testing the connectivity for a new VLAN The devices in the VLAN are connected to a FortiSwitch device that is managed by FortiGate Quarantine is disabled on FortiGate While testing the administrator noticed that devices can ping FortiGate and FortiGate can ping the devices The administrator also noticed that inter-VLAN communication works However intra-VLAN communication does not work Which scenario is likely to cause this issue?

The FortiSwitch MAC address table is missing entries

The native VLAN configured on the ports is incorrect

The FortiGate ARP table is missing entries

Access VLAN is enabled on the VLAN

NEW QUESTION 20
Refer to the exhibit.

Examine the FortiSwitch security policy shown in the exhibit
If the security profile shown in the exhibit is assigned to all ports on a FortiSwitch device for 802 1X authentication which statement about the switch is correct?

FortiSwitch cannot authenticate multiple devices connected to the same port

FortiSwitch will try to authenticate non-802 1X devices using the device MAC address as the username and password

FortiSwitch will assign non-802 1X devices to the onboarding VLAN

All EAP messages will be terminated on FortiSwitch

NEW QUESTION 21
An administrator has configured an SSID in bridge mode for corporate employees All APs are online and provisioned using default AP profiles Employees are unable to locate the SSID to conned Which two configurations can the administrator verify? (Choose two)

Verify that the broadcast SSID option is enabled in the SSID configuration

Verify that the Block Intra-SSID Traffic (intra-vap-privacy) option in the SSID configuration is disabled

Verify that the SSID to an AP group that should be broadcasting the SSID is applied

Verify that the SSID is manually applied on AP profiles for both 2 4 GHz and 5 GHz radios

NEW QUESTION 22
Refer to the exhibits.

Exhibit.

Examine the troubleshooting outputs shown in the exhibits
Users have been reporting issues with the speed of their wireless connection in a particular part of the wireless network The interface that is having issues is the 2 4 GHz interface that is currently configured on channel 6 The administrator of the wireless network has investigated and surveyed the local RF environment using the tools available at the AP and FortiGate Which configuration would improve the wireless connection?

Change the AP 2 4 GHz channel to 11

Change the AP 2 4 GHz channel to 1.

Change the AP 2 4 GHz channel to 9.

Change the AP 2 4 GHz channel to 13.

NEW QUESTION 23

Wireless guest users are unable to authenticate because they are getting a certificate error while loading the captive portal login page.This URL string is the HTTPS POST URL guest wireless users see when attempting to access the network using the web browser

Which two settings are the likely causes of the issue? (Choose two.)

The external server FQDN is incorrect

The wireless user’s browser is missing a CA certificate

The FortiGate authentication interface address is using HTTPS

The user address is not in DDNS form

NEW QUESTION 24
Which two statements about FortiSwitchmanager are true1? (Choose two)

Per-device management is the default management mode on FortiManager

FortiManager obtains the FortiSwitch status information by querying the FortiGate REST API every three minutes

If the administrator makes any changes on FortiSwitch manager they must also install those changes on FortiGate so that those changes are applied on the managed switches

Any switch discovered or authorized on FortiGate must be added manually on FortiSwitch manager

NEW QUESTION 25
Refer to the exhibit.

Examine the FortiManager configuration and FortiGate CLI output shown in the exhibit An administrator is testing the NAC feature The test device is connected to a managed FortiSwitch device
{S224EPTF19″53C7)onpOrt2
After applying the NAC policy on port2 and generating traffic on the test device the test device is not matching the NAC policy therefore the test device remains m the onboarding VLAN Based on the information shown in the exhibit which two scenarios are likely to cause this issue? (Choose two.)
